The G3 operator interface panels give you complete HMI functionality
for PLCs, motor drives and other communications-capable devices.
With Ethernet as standard on all G3 models, you can network-enable
any serial devices connected to the panel. In addition to the G3,
We also offer operator panels, plus message centers, slave displays
and large digit displays in a variety of configurations.

:: G315 ::

• 15-inch TFT Active Matrix 32K Color XGA 1024 X 768 Pixel LCD
• 3rd Generation HMI
• Configured using Software
• 10-button keypad for on-screen menus
• Three front panel LED indicators
• Resistive Analog Touchscreen
• Up to 6 RS-232/422/485 Communications Ports (2 RS-232 and 2 RS-422/485 on board, 1 RS-232 and 1 RS422/485 on Optional Communications Card)
• 10 Base T/100 Base-TX Ethernet Port Supports Multiple Protocols Simultaneously
• Built-in Web Server and FTP Server/Client
• USB Port to Download the Unit’s Configuration from a PC or for Data Transfers to a PC
• Unit’s Configuration is Stored in Non-volatile Memory (32 Mbyte Flash)
• CompactFlash Socket for Database/Recipe Storage and Data Logging
• Power unit from 24 VDC +/- Supply



:: G310 ::

• 3rd Generation HMI
• Configured using Software
• Powerful 32-bit ColdFire Processor
• Configuration and Firmware are Stored in 8 MB of Non-volatile FLASH Memory
• 10.4" 256-color 640x480 TFT Display
• Resistive Analog Touchscreen
• Dedicated MENU Key and 7 Soft-Keys
• Integrated Protocol Converter
• Up to 5 RS-232/422/485 Serial Ports
• 10-Base-T/100-Base-TX Ethernet Port
• Remote Web Access and Control Facility
• USB Port for Configuration Download
• Compact Flash Socket
• UL Listed for use in Hazardous Locations. (See literature for class and division details.)
• NEMA 4X / IP66 Front Panel
• 24V DC Operation



:: G308 ::

• 8.4" 256-color 640x480 TFT Display (G308A)
• 7.7" 256-color 640x480 DSTN Display (G308C)
• 3rd Generation HMI
• Configured using Software (Must use Build 187 or later for G308A)
• Powerful 32-bit ColdFire Processor
• Configuration and Firmware are Stored in 8MB of Non-volatile FLASH Memory
• Resistive Analog Touchscreen
• Dedicated MENU Key and 6 Soft-Keys
• Integrated Protocol Converter
• Up to 5 RS-232/422/485 Serial Ports
• 10-Base-T/100-Base-TX Ethernet Port
• Remote Web Access and Control Facility
• USB Port for Configuration Download
• Compact Flash Socket
• UL Listed for use in Hazardous Locations. (See literature for class and division details.)
• NEMA 4X / IP66 Front Panel
• 24V DC Operation

: : G306 ::

• 5.7-inch TFT Active Matrix 256 Color QVGA 320 X 240 pixel LCD (G306A)
• 5.7-inch Ultra-STN Passive Matrix 256 Color QVGA 320 X 240 pixel LCD (G306C)
• 3rd Generation HMI
• Configured using Software
• 5-button keypad for on-screen menus
• Three front panel LED indicators
• Resistive Analog Touchscreen
• Up to 5 RS-232/422/485 Serial ports
• 10 Base T/100 Base-TX Ethernet Port
• Remote Web Access and Control Facility
• USB Port for Configuration Download
• Configuration is stored in non-volatile memory: 8 Mbyte Flash for G306A and
• 4 Mbyte Flash for G306C
• CompactFlash socket
• UL Listed for use in Hazardous Locations (See G306C literature for class and division details.)
• NEMA 4X / IP66 Front Panel
• Power unit from 24 VDC

:: G303 ::

• 3rd Generation HMI
• Configured using Software
• Powerful 32-bit ColdFire Processor
• Configuration and Firmware are Stored in 4MB of Non-volatile FLASH Memory
• 3" Monochrome 128x64 Pixel Display
• 8 Relegendable Function Keys
• Numeric Keypad, System Keys, Soft Keys
• Integrated Protocol Converter
• Up to 5 RS-232/422/485 Serial Ports
• 10-Base-T/100-Base-TX Ethernet Port
• Remote Web Access and Control Facility
• USB Port for Configuration Download
• Compact Flash Socket for Data Logging
• NEMA 4X / IP66 Front Panel
• UL Listed for use in Hazardous Locations. (See literature for class and division details.)
• 24V DC Operation

Let's make this simple

Sigma Data Station (SDS)

Protocol conversion. Ethernet gateway. IT-ready data logging. Its all here.



Handles data like SCADA but for thousands less.





AUTOMATION - CONTROL - MANAGEMENT- REMOTE MANAGEMENT -MONITORING -LOGGING - PREVENTION

Sigma Data Station Plus; USB, RS232/422/485; Ethernet; 24V; 2Mb Flash; 2Mb SDRAM

The Sigma Data Station Plus was designed to act as a nexus for industrial data collection and management. The unit offers multiple protocol conversion, data logging and remote machine access. With three built in serial ports and a 10 Base-T/100 Base-TX Ethernet port, the unit performs protocol conversion, allowing disparate devices to communicate seamlessly with one another. The Ethernet port supports up to four protocols simultaneously so even Ethernet to Ethernet protocols can be converted. The CompactFlash card allows data to be collected and stored for later review. The files are stored in simple CSV file format allowing common applications, such as Microsoft Excel and Microsoft Access, to view and manage the data. The free Websync utility provides a means to synchronize the files with a PC's hard drive for permanent storage. The CompactFlash card may also be used to load new configuration files into the Data Station.

The built-in web server allows log files to be retrieved manually, and also provides access to the unique "Virtual HMI". The virtual HMI is programmed just like G303 (3" mono) or G306 (6" color) HMI touchscreens. Any standard web browser such as internet Explorer or Netscape may be used to monitor or control the HMI from a PC anywhere in the world.

The USB port may be used for blazing fast file downloads, or to mount the Sigma Data Station's CompactFlash card as an

external drive to your PC. The Data Station's DIN rail mounting saves time and panel space and snaps easily onto standard top hat (T) profile DIN rail.
The Sigma Data Station is programmed with Crimson 2.0 software for Windows 2000 or later

platforms. The software is an easy to use graphical interface which can be purchased as part of a kit that includes a manual and cables.







view & control from anywhere in the world



Data Station, Multiple Protocol, Data Logger 6" Virtual HMI

• Protocol conversion feature converts numerous protocols simultaneously
• Compactflash slot allows process data to be logged directly to csv files
• Virtual hmi offers built-in pc-based scada functionality
• Webserver provides worldwide access to data logs and virtual hmi
• Extensive built-in driver list allows easy data mapping to plcs, pcs, and scada systems
• Alarm notifications can be sent via email or text messages
• 10 Base-t/100 base-tx ethernet connection can connect to an unlimited number of devices via four protocols simultaneously

The Data Station Plus was designed to act as a nexus for industrial data collection and management. The unit offers multiple protocol conversion, data logging and remote machine access. With three built in serial ports and a 10 Base-T/100 Base-TX Ethernet port, the unit performs protocol conversion, allowing disparate devices to communicate seamlessly with one another. The Ethernet port supports up to four protocols simultaneously so even Ethernet to Ethernet protocols can be converted.
The CompactFlash card allows data to be collected and stored for later review. The files are stored in simple CSV file format allowing common applications, such as Microsoft Excel and Access, to view and manage the data. The free Websync utility provides a means to synchronize the files with a PC’s hard drive for permanent storage. The CompactFlash card may also be used to load new configuration files into the Data Station.
The built-in web server allows log files to be retrieved manually, and also provides access to the unique 'virtual HMI'. The virtual HMI is programmed just like the G3 series of HMI. Any standard web browser such as Internet Explorer or Netscape may be used to monitor or control the HMI from a PC anywhere in the world.
The USB port may be used for blazing fast file downloads, or to mount the Data Station’s CompactFlash card as an external drive to your PC. The Data Station’s DIN rail mounting saves time and panel space and snaps easily onto standard top hat (T) profile DIN rail.



Data Station, Multiple Protocol, Data Logger 10" Virtual HMI

• Protocol conversion feature converts numerous protocols simultaneously
• Compactflash slot allows process data to be logged directly to csv files
• Virtual hmi offers built-in pc-based scada functionality
• Webserver provides worldwide access to data logs and virtual hmi
• Extensive built-in driver list allows easy data mapping to plcs, pcs, and scada systems
• Alarm notifications can be sent via email or text messages
• 10 Base-t/100 base-tx ethernet connection can connect to an unlimited number of devices via four protocols simultaneously

The Data Station Plus was designed to act as a nexus for industrial data collection and management. The unit offers multiple protocol conversion, data logging and remote machine access. With three built in serial ports and a 10 Base-T/100 Base-TX Ethernet port, the unit performs protocol conversion, allowing disparate devices to communicate seamlessly with one another. The Ethernet port supports up to four protocols simultaneously so even Ethernet to Ethernet protocols can be converted.
The CompactFlash card allows data to be collected and stored for later review. The files are stored in simple CSV file format allowing common applications, such as Microsoft Excel and Access, to view and manage the data. The free Websync utility provides a means to synchronize the files with a PC’s hard drive for permanent storage. The CompactFlash card may also be used to load new configuration files into the Data Station.

The built-in web server allows log files to be retrieved manually, and also provides access to the unique 'virtual HMI'. The virtual HMI is programmed just like the G3 series of HMI. Any standard web browser such as Internet Explorer or Netscape may be used to monitor or control the HMI from a PC anywhere in the world.

The USB port may be used for blazing fast file downloads, or to mount the Data Station’s CompactFlash card as an external drive to your PC. The Data Station’s DIN rail mounting saves time and panel space and snaps easily onto standard top hat (T) profile DIN rail.

Data Logger, Virtual HMI

• Provides Enhanced Features for Data Acquisition or Multi-zone PID Control Applications
• Webserver Provides Worldwide Access to Data Logs and Virtual HMI (SX & GT)
• Virtual HMI Offers Built-in PC-based SCADA Functionality (SX & GT)
• Performs Hierarchical Control of Other Modules in the Modular Controller Series
• Stores Module Configuration Information and Automatically Reprograms Replaced Modules
• Extensive Built-in Driver List Allows Easy Data Mapping to PLCs, PCs, and SCADA Systems
• Independent Serial Ports Provide Virtually Unlimited Integration Methods
• 10 Base-T/100 Base-TX Ethernet Connection Provides Networking Capability
• Supports up to 16 Modular Controller Series Modules
• CompactFlash Slot Allows Process Data to be Logged Directly to CSV Files (SX & GT)

Master Data Logger, Virtual HMI

• Protocol Conversion Feature Converts Numerous Protocols Simultaneously
• CompactFlash  Slot Allows Process Data to be Logged Directly to CSV Files (DSPSX & DSPGT)
• Virtual HMI Offers Built-in PC-based SCADA Functionality (DSPSX & DSPGT)
• Webserver Provides Worldwide Access To Data Logs And Virtual HMI (DSPSX & DSPGT)
• Extensive Built-in Driver List Allows Easy Data Mapping to PLCs, PCs, and SCADA Systems
• Alarm Notifications can be sent via Email or Text Messages (DSPSX & DSPGT)
• 10 Base-T/100 Base-TX Ethernet Connection Can Connect To An Unlimited Number Of Devices Via Four Protocols Simultaneously
• Independent Serial Ports Provide Virtually Unlimited Integration Methods

The Data Station Plus was designed to act as a nexus for industrial data collection and management. The unit offers multiple protocol conversion, data logging and remote machine access. With three built in serial ports and a 10 Base-T/100 Base-TX Ethernet port, the unit performs protocol conversion, allowing disparate devices to communicate seamlessly with one another. The Ethernet port supports up to four protocols simultaneously so even Ethernet to Ethernet protocols can be converted.
The CompactFlash card allows data to be collected and stored for later review. The files are stored in simple CSV file format allowing common applications, such as Microsoft Excel and Access, to view and manage the data. The free Websync utility provides a means to synchronize the files with a PC’s hard drive for permanent storage. The CompactFlash card may also be used to load new configuration files into the Data Station.

The built-in web server allows log files to be retrieved manually, and also provides access to the unique virtual HMI. The virtual HMI is programmed just like the G3 series of HMI. Any standard web browser such as Internet Explorer or Netscape may be used to monitor or control the HMI from a PC anywhere in the world.

The USB port may be used for blazing fast file downloads, or to mount the Data Station’s CompactFlash card as an external drive to your PC. The Data Station’s DIN rail mounting saves time and panel space and snaps easily onto standard top hat (T) profile DIN rail.

Digital I/O Module Solid State

• Adds remote I/O capability to the Modular Controller series
• Eight input, six output digital module
• Inputs isolated from outputs
• Inputs independently switch selectable for sink or source signals
• Inputs independently configurable for high or low active state
• Inputs independently switch selectable for high or low frequency signals
• Relay or NFET output models available

The Model CSDIO series modules are digital I/O modules designed for use with the Modular Controller Series. The CSDIO14 offers eight inputs and six outputs that can be used to monitor contact or sensor inputs and actuate relays, solenoids, PLC inputs, etc.

The inputs accept standard DC inputs or contact closures, and are configured for Sink/Source signals via external switches. Additionally, each input has a switch selectable input filter that can be used to prevent contact bounce. Each input may also be software configured as a high-active or low-active input. The modules are available with relay or NFET outputs that are capable of switching up to one amp each (NFET DC only). For applications requiring large loads to be controlled, several DIN rail mount relays are available.

Digital I/O Module Relay

• Adds remote I/O capability to the Modular Controller series
• Eight input, six output digital module
• Inputs isolated from outputs
• Inputs independently switch selectable for sink or source signals
• Inputs independently configurable for high or low active state
• Inputs independently switch selectable for high or low frequency signals
• Relay or NFET output models available

The Model CSDIO series modules are digital I/O modules designed for use with the Modular Controller Series. The CSDIO14 offers eight inputs and six outputs that can be used to monitor contact or sensor inputs and actuate relays, solenoids, PLC inputs, etc.
The inputs accept standard DC inputs or contact closures, and are configured for Sink/Source signals via external switches. Additionally, each input has a switch selectable input filter that can be used to prevent contact bounce. Each input may also be software configured as a high-active or low-active input. The modules are available with relay or NFET outputs that are capable of switching up to one amp each (NFET DC only). For applications requiring large loads to be controlled, several DIN rail mount relays are available.

8 Channel Analogue I/P Module Current

• Dedicated high density input modules for the modular controller series
• Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
• ±10 v and 0/4-20 ma input versions fully scalable
• ±10 v and 0/4-20 ma input versions available with 100
• Point linearization
• Unused inputs can be disabled to increase overall reading rate
• Ideal for data-acquisition applications
• Auto addressing minimizes configuration time
• Can be used in conjunction with any cs series modules

of our Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.
Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.

8 Channel Analogue I/P Module Current Linearised

• Dedicated high density input modules for the modular controller series
• Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
• ±10 v and 0/4-20 ma input versions fully scalable
• ±10 v and 0/4-20 ma input versions available with 100
• Point linearization
• Unused inputs can be disabled to increase overall reading rate
• Ideal for data-acquisition applications
• Auto addressing minimizes configuration time
• Can be used in conjunction with any cs series modules

our Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.
Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.

8 Channel Analogue I/P Module Voltage



• Dedicated high density input modules for the modular controller series
• Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
• ±10 v and 0/4-20 ma input versions fully scalable
• ±10 v and 0/4-20 ma input versions available with 100
• Point linearization
• Unused inputs can be disabled to increase overall reading rate
• Ideal for data-acquisition applications
• Auto addressing minimizes configuration time
• Can be used in conjunction with any cs series modules

our Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.
Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.

8 Channel Thermpocouple I/P Module



• Dedicated high density input modules for the modular controller series
• Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
• ±10 v and 0/4-20 ma input versions fully scalable
• ±10 v and 0/4-20 ma input versions available with 100
• Point linearization
• Unused inputs can be disabled to increase overall reading rate
• Ideal for data-acquisition applications
• Auto addressing minimizes configuration time
• Can be used in conjunction with any cs series modules

The Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.

Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.



6 Channel RTD I/P Module

• Dedicated high density input modules for the modular controller series
• Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
• ±10 v and 0/4-20 ma input versions fully scalable
• ±10 v and 0/4-20 ma input versions available with 100
• Point linearization
• Unused inputs can be disabled to increase overall reading rate
• Ideal for data-acquisition applications
• Auto addressing minimizes configuration time
• Can be used in conjunction with any cs series modules

The Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.
Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.



6 Channel RTD I/P Module

Dedicated high density input modules for the modular controller series
Models available to accept ±10 v, 0/4-20 ma, thermocouple and rtd inputs
±10 v and 0/4-20 ma input versions fully scalable
±10 v and 0/4-20 ma input versions available with 100
Point linearization
Unused inputs can be disabled to increase overall reading rate
Ideal for data-acquisition applications
Auto addressing minimizes configuration time
Can be used in conjunction with any cs series modules
The Modular Controller series offers a cost effective solution to integrating multi-zone PID control, data acquisition and I/O into your PC, DCS or PLC control system. You can drag and drop controller data to PLC registers in seconds using point-and-click data mapping from an extensive menu of built-in serial and Ethernet drivers. No tedious PLC code to write.
Instantly Ethernet-enable your PLC for free! Not only are programming costs slashed, you can eliminate costly add-on I/O and analog cards and solve applications simply using an inexpensive brick PLC.
The high-density DIN rail design saves panel space and eliminates cutouts. All modules can be hot-swapped -- the master automatically programs a replaced module.



4 Channel Analοgue O/P module

• High density analog output module for the modular controller series
• Available outputs include 0 to 5 VDC, 0 to 10 VDC, ±10 VDC, and 0/4-20 mA DC
• Outputs are isolated from each other and from the backplane
• Outputs are software configured and fully scalable
• Auto addressing minimizes configuration time
• Can be used in conjunction with any CS series modules

The model CSOUT is an analog output module designed for use with the Modular Controller Series. The module provides four isolated outputs that are independently programmable for output ranges of 0-5V, 0-10V, +/-10V, 0- 20mA, or 4-20mA. Internal scaling is provided to accommodate virtually any application.
The modules connect and communicate via a backplane connection to the CSMSTR Modular Controller Series Master. The CSMSTR, equipped with serial ports as well as an Ethernet port, allows the system to share data with PCs, PLCs, and SCADA systems. The Master supports up to 16 CS Series modules (refer to the 'Power' specifications).
