Magnetostrictive Level Transmitters

Model 100 High Accuracy Level Transmitter

The Magnetostrictive 100 is suitable for Product and/or Interface level measurement. Featuring HART or Fieldbus protocol & an accuracy of +/- 0.01% FS.

Features

  • 2 wire loop powered, 24 Vdc
  • ATEX Approved
  • +/- 1mm Accuracy
  • Product Level and Interface with one Gauge
  • 60 Year MTBF (FMECA Reports)
  • No field calibration
  • 316L / Monel / Hastelloy
  • Gauge length from 0.3 to 22m
  • Operating temperatures - 200°C to +430°C
  • Operating pressure up to 207 Bar

Approvals

  • ABS (Type Approval)
  • AAR
  • ATEX IS
  • ATEX XP
  • Cenelec XP
  • CRN
  • CSA
  • FM
  • GOST Russia
  • Lloyds Registration
  • NEPSI

Model 200 Magnetostrictive Level Transmitter

Model 200 is designed to Mount Externally to Model 26 Magnetic Level Gauge or any Other Level Gauge.

  • High Accuracy: 0.01% of Full Scale
  • No field calibration
  • Total and/or Interface Level Measurement
  • Built-in RFI / EMI Filter
  • No Drift Due to Dielectric Constant Changes, Vapor Composition Changes, Temperature Changes or Pressure Changes
  • Process Temperature Range: -320ºF to 800ºF (-196ºC to 427ºC) with Options

Approvals

  • ABS (Type Approval)

Model 500

The 500 is a cost effective alternative to capacitance probes, displacers, ultrasonic meters and radar transmitters and is based on the Same Magnetostrictive Principle as the AT100 Model. Model 500 is a Compact Magnetostrictive Liquid Level Transmitter for Direct Insertion for Total and Interface Measurement.

Features

  • 2 wire loop powered, 24 Vdc
  • ATEX Approved
  • +/- 1mm Accuracy
  • No field calibration
  • 316L
  • Gauge length from 0.3 to 4.8m
  • Operating temperatures - 40°C to +121°C
  • Operating pressure up to 124 Barg

Approvals

  • AAR
  • ATEX IS
  • ATEX XP
  • Cenelec
  • Cenelec XP
  • CSA
  • FM
  • Lloyds Registration

Hydrostatic Head

One of the oldest and most common methods of measuring liquid level is to measure the pressure exerted by a column (or head) of liquid in the vessel. We offer solutions with submersible sensors and through the tank wall sensor options.

400 series

The 400 series of submersible pressure transmitters includes a number of completely submersible pressure-sensing transmitter models ranging from 0 to 1m water column to 0 to 500m, that contain an air vent tube for providing a pressure differential relationship between the hydrostatic head and the atmosphere. The transducer contains associated electronic circuitry for providing an analogue output, has an IP 68 protection rating, and requires a 24 Vdc ± 10% Power Supply
One of the regular applications for these transmitters is tank level monitoring & control



Ultrasonic sensors provide a cost effective sensing method with unique properties not possessed by other sensing technologies. By using a wide variety of ultrasonic transducers and several different frequency ranges, an ultrasonic sensor can be designed to solve many application problems that are cost prohibitive or simply cannot be solved by other sensors. Ultrasonic sensors continuously emit high frequency sound pulses inaudible to the human ear  which travel away from the sensor, hit the surface of the target and are reflected back to the sensor. The sensor electronics measure the time taken by the signals to return after being reflected by the target surface.

Since the speed of sound is affected by air temperature, our ultrasonic sensors include a built-in temperature sensor. Level/distance measurements are automatically temperature compensated throughout the operating temperature range of the sensor.

Classic applications include proximity sensing, object presence or absence, obstacle detection for automated vehicles, distance measuring, level measuring, etc etc


highlights

  • Direct measuring value output in mm/cm or % via LED display
  • Temperature compensation  for accurate measuring with fluctuating temperature
  • accuracy with temperature drift internal compensation, ±  1%
  • Numerical sensor setting via LED display  for a complete pre-setting of the sensor
  • 1 or 2 pnp or npn switching outputs for all controls
  • Analogue output 4-20 mA and 0-10 V  for two signals in one device (optional), reverse polarity protection
  • Operating voltage 9-30 V for application in various supply networks
  • Additional teach-in-function for a traditional setting of detect points
  • Automatic synchronisation for simultaneous operation of up to ten sensors in confined spaces
  • Automatic switchover between current and voltage output  for simple operation
  • Housing material brass sleeve, nickel-plated, plastic parts, PBT, TPU (stainless steel optional)
  • protection rating IP67
  • vibration & shock complies to IEC 60068-2-27



Different operating modes and device configurations enable our ultrasonic sensing systems to be used in most conceivable automation applications


detection ranges

30-250mm 60-350mm 200-1300mm 350-3400mm 600-6000mm







Output versions







Useful accessories

  • Angled or straight M12 Socket  connector with cable
  • Mounting set , stainless steel (304S15) angle bracket
